WLST script to add DataSource and DBAdapter EIS Connection Factory

Michel Schildmeijer 5
0 0
Read Time:3 Minute, 51 Second

Creating a EIS ConnectionFactory in your Database Adapter can be done with the WebLogic Administration Console, but of course this is also “scriptable”. What I needed was a script that created a Data Source with EIS Connection factory bound to the specific datasource.

First I created a properties file, let’s call it DsCf.properties. Everything between <> should be replaced with your own values:

# Propertie file for creating datasource and EIS DB Adapter
# Created by Michel Schildmeijer
# Domain settings
domainname="<your WLS DOMAIN>"
adminurl=<WLS HOST:Admin Port>
adminusername=weblogic
adminpassword=<passwd weblogic>
#datasource settings
datasourcename=<Name DataSource>
datasourcedatabasename=<database>
datasourcetarget=<targeted manaegd server>
datasourcefilename= datasourcename + '.xml'
datasourcejndiname= 'jdbc/' + datasourcename
datasourcedriverclass=oracle.jdbc.OracleDriver
datasourceurl=jdbc:oracle:thin:@<db host>:1521:<db sid>
datasourceusername=<db user>
datasourcepassword=<db user password
datasourcetestquery=SQL SELECT * FROM DUAL
#EIS Connection Factory settings
connfactname=eis/DB/<Connection factory Name>

Second, I created a WLST script to execute these properties and added the DataSource and ConnectionFactory. See the script below.

When running on a UNIX or linux system, navigate to the WLS DOMAIN DIR /bin( Specified during domaincreation) like /app/oracle/middleware/user_projects/domains/<Your domain>/bin and run

./setDomainEnv.sh

After this you are able to deploy the DataSource en ConnectionFactory:

java weblogic.WLST loadProperties DsCf.properties

After finished you can check in the WebLogic Admin Console to see:

  • If datasource is created
  • If in your outbound connections of the database adapter the EIS connection factory with binding to the DataSource has been created.

Script DsCf.py



import os
import time
domainName = domainname
adminURL= adminurl
adminUserName= adminusername
adminPassword= adminpassword
dsName= datasourcename
dsFileName= datasourcefilename
dsDatabaseName=datasourcedatabasename
datasourceTarget=datasourcetarget
dsJNDIName=datasourcejndiname
dsDriverName=datasourcedriverclass
dsURL=datasourceurl
dsUserName=datasourceusername
dsPassword=datasourcepassword
dsTestQuery=datasourcetestquery
connect(adminUserName, adminPassword, adminURL)
TargetServerName='soa_server1'
edit()
startEdit()
cd('/')
cmo.createJDBCSystemResource(dsName)
cd('/JDBCSystemResources/' + dsName + '/JDBCResource/' + dsName)
cmo.setName(dsName)
cd('/JDBCSystemResources/' + dsName + '/JDBCResource/' + dsName + '/JDBCDataSourceParams/' + dsName )
set('JNDINames',jarray.array([String('jdbc/' + dsName )], String))
cd('/JDBCSystemResources/' + dsName + '/JDBCResource/' + dsName + '/JDBCDriverParams/' + dsName )
cmo.setUrl(dsURL)
cmo.setDriverName( dsDriverName )
cmo.setPassword(dsPassword)
cd('/JDBCSystemResources/' + dsName + '/JDBCResource/' + dsName + '/JDBCConnectionPoolParams/' + dsName )
cmo.setTestTableName(dsTestQuery)
cd('/JDBCSystemResources/' + dsName + '/JDBCResource/' + dsName + '/JDBCDriverParams/' + dsName + '/Properties/' + dsName )
cmo.createProperty('user')
cd('/JDBCSystemResources/' + dsName + '/JDBCResource/' + dsName + '/JDBCDriverParams/' + dsName + '/Properties/' + dsName + '/Properties/user')
cmo.setValue(dsUserName)
cd('/JDBCSystemResources/' + dsName + '/JDBCResource/' + dsName + '/JDBCDriverParams/' + dsName + '/Properties/' + dsName )
cmo.createProperty('databaseName')
cd('/JDBCSystemResources/' + dsName + '/JDBCResource/' + dsName + '/JDBCDriverParams/' + dsName + '/Properties/' + dsName + '/Properties/databaseName')
cmo.setValue(dsDatabaseName)
cd('/JDBCSystemResources/' + dsName + '/JDBCResource/' + dsName + '/JDBCDataSourceParams/' + dsName )
cmo.setGlobalTransactionsProtocol('OnePhaseCommit')
cd('/SystemResources/' + dsName )
set('Targets',jarray.array([ObjectName('com.bea:Name=' + datasourceTarget + ',Type=Server')], ObjectName))
save()
activate()
print 'Data source ' + dsName + ' configured'

#Connect
#appPath='/app/oracle/middleware/soa11g/soa/connectors/DbAdapter.rar'
#planPath='/app/oracle/middleware/soa11g/soa/connectors/DbAdapterPlanGenerated.xml'
oracleHome = os.environ.get(“ORACLE_HOME”)
appPath= oracleHome + 'soa/connectors/DbAdapter.rar'
planPath=oracleHome + 'soa/connectors/DbAdapterPlanGenerated.xml'

CFName=connfactname
dsName=datasourcename
appName='DbAdapter'
moduleOverrideName=appName+'.rar'
moduleDescriptorName='META-INF/weblogic-ra.xml'
def makeDeploymentPlanVariable(wlstPlan, name, value, xpath, origin='planbased'):
while wlstPlan.getVariableAssignment(name, moduleOverrideName, moduleDescriptorName):
wlstPlan.destroyVariableAssignment(name, moduleOverrideName, moduleDescriptorName)
while wlstPlan.getVariable(name):
wlstPlan.destroyVariable(name)
variableAssignment = wlstPlan.createVariableAssignment( name, moduleOverrideName, moduleDescriptorName )
variableAssignment.setXpath( xpath )
variableAssignment.setOrigin( origin )
wlstPlan.createVariable( name, value )
             def main():
                     connect(adminUserName, adminPassword, adminURL)
                     edit()
                           try:
                           startEdit()
                           planPath = get('/AppDeployments/DbAdapter/PlanPath')
                           print '__ Using plan ' + planPath
                           myPlan=loadApplication(appPath, planPath)
                           print '___ BEGIN change plan'
                           makeDeploymentPlanVariable(myPlan, 'ConnectionInstance_' '+ CFName' +'_JNDIName_abc123XXX','+ CFName', '/weblogic-connector/outbound-resource-adapter/connection-definition-group/[connection-factory-interface="javax.resource.cci.ConnectionFactory"]/connection-instance/[jndi-name="'+ CFName + '"]/jndi-name')
                           makeDeploymentPlanVariable(myPlan, 'ConfigProperty_xADataSourceName_'+ dsName +'_abc123XXX',dsName, '/weblogic-connector/outbound-resource-adapter/connection-definition-group/[connection-factory-interface="javax.resource.cci.ConnectionFactory"]/connection-instance/[jndi-name="'+ CFName + '"]/connection-properties/properties/property/[name="xADataSourceName"]/value')
                           print '___ DONE change plan'
                           myPlan.save();
                           save();
                           activate(block='true');
                           cd('/AppDeployments/DbAdapter/Targets');

                           redeploy(appName, planPath,targets=cmo.getTargets());
                           print 'EIS Connection factory ' + CFName + 'using' + dsName + ' configured';
                    except:
                           stopEdit('y')
main()
