Oracle Designer Report – SQL Script for Roles vs. Modules

Lucas Jellema

On my current project, we had a request from the customer to produce an overview of all the (Database) Roles in the Application with a list of Modules, Screens and Reports, that are assigned to those Roles. Since I could not find this overview in shipped Repository Reports, and I know I did not implement it in the Repository Object Browser, I quickly wrote the following SQL Query, that you can execute as any Designer (Repository) User:

exec jr_context.set_workarea('AGS_WA');

select case rn
       when 1
       then role
       end role
, module||' - '||top_title module
from ( select module
         , mde.top_title
         , role
         , row_number() over (partition by
                                    order by
                                   ) rn
         from ci_role_module_accesses rms
         , ci_roles rle
         , ci_general_modules mde
         where = rms.role_reference
         and rms.general_module_reference =

The result looks something like:

ROLE                           MODULE
------------------------------ ------------------------------------------------------------
AGS$ALG                        AGS0000F - PKS Startup Scherm
                               AGS2910R - Overzicht catalogi op postniveau
                               AGS2912R - Overzicht catalogi op elementniveau
                               AGS2920R - Overzicht variabelen.
                               AGS2930R - Overzicht oppervlaktetypes
AGS$BHR                        AGS00010F - Onderhouden statische Parameters
                               AGS1100F - Onderhouden Stamgegevens autorisatie
                               AGS1200F - Onderhouden gebruikersgroepen en privileges
                               AGS1201L - Privileges
                               AGS1300F - Onderhouden gebruikers en gebruikersgroepen
                               AGS1410R - Overzicht rechten per gebruikersgroep
                               AGS1420R - Overzicht gebruikers
                               AGS1430R - Overzicht gebruikersgroepen
                               AGS1440R - Overzicht privileges.
                               AGS2500F - Onderhouden subsidieregelingen.
                               AGS2550F - Onderhouden variantnummers
                               AGS2600F - Onderhouden variabelen.
                               AGS2700F - Onderhouden oppervlaktetypes
                               AGS2800F - Onderhouden eenheden
                               AGS2900F - Onderhouden gebieden
                               AGS3501L - Overzicht gebruikers
AGS$BWGBHR                     AGS5400F - Wijzigen eigenaar machtiging
AGS$BWGOND                     AGS5100F - Onderhouden machtigingen
                               AGS5200F - Verwijderen machtigingen
                               AGS5300F - Onderhouden gebruikerstoegang machtigingen
                               AGS5800F - Geforceerde statuswijziging machtiging
AGS$BWGRPN                     AGS5100Q - Raadplegen machtigingen
