Oracle Service Bus: enable / disable proxy service with WLST

Read Time:2 Minute, 51 Second

I was looking for a way how to enable or disable a proxy service within Oracle Service Bus 11g with WLST (WebLogic Scripting tool)

Here’s the way I found out to do it.

I created a python script to be called with wlst, osb_enable_service.py

First set your environment settings right:

source $WL_DOMAIN_DIR/bin/setDomainEnv.sh ($WL_DOMAIN_DIR and $WL_DOMAIN should be set in your OS profile, like .bash_profile or .profile)

Call the script with wlst: $WL_HOME/common/bin/wlst.sh Â osb_enable_service.py

Fill in the requirements…

Project Name: CustomProvider

Proxy Service :ReportAlertProxy

type in : enable or disable –>disable

Connecting to t3://amssrv……:7001 with userid weblogic …

Successfully connected to Admin Server ‘AdminServer’ that belongs to domain ‘osb_trn_domain’.

Warning: An insecure protocol was used to connect to the

server. To ensure on-the-wire security, the SSL port or

Admin port should be used instead.

Location changed to domainRuntime tree. This is a read-only tree with DomainMBean as the root.

For more help, use help(domainRuntime)

(‘… after session. Session is: ‘, SessionScript1294672366163)

(‘SessionMBean is: ‘, [MBeanServerInvocationHandler]com.bea:Name=SessionManagement,Type=com.bea.wli.sb.management.configuration.SessionManagementMBean)

Session was created … SessionScript1294672366163

Disabling ReportAlertProxy

has been Â completed

Disconnected from weblogic server: AdminServer

Exiting WebLogic Scripting Tool.

To be sure, check in the OSB Console if the script did it’s work:

Now, do the same to enable:

Project Name: CustomProvider

Proxy Service :ReportAlertProxy

type in : enable disable –>enable

And check again in the OSB Console:

Here’s the script:

from com.bea.wli.sb.management.configuration import SessionManagementMBean

from com.bea.wli.sb.management.configuration import ALSBConfigurationMBean

from com.bea.wli.config import Ref

from java.lang import String

from com.bea.wli.monitoring import StatisticType

from com.bea.wli.config import Ref

from com.bea.wli.sb.util import Refs

from com.bea.wli.sb.management.configuration import CommonServiceConfigurationMBean

from java.lang import String

from com.bea.wli.monitoring import StatisticType

from com.bea.wli.config import Ref

from com.bea.wli.sb.util import Refs

from com.bea.wli.sb.management.configuration import CommonServiceConfigurationMBean

admin_server=”<WebLogic Server host>“

admin_server_poort=”7001″

wluser=”weblogic”

wlpassword=”<wl_password>“

domein=<your_domain name>“

project=raw_input(“Project Name: ” )

service=raw_input(“Proxy Service :”)

action=raw_input(“type in : enable disable –>”)

connect(wluser, wlpassword, ‘t3://’+ admin_server + ‘:’ + admin_server_poort)

domainRuntime()

# Create a session name

#sessionName =

sessionName = String(“SessionScript”+Long(System.currentTimeMillis()).toString())

print(‘… after session. Session is: ‘, sessionName)

# Get the session MBean and create a session

sessionMBean = findService(SessionManagementMBean.NAME,SessionManagementMBean.TYPE)

print(‘SessionMBean is: ‘, sessionMBean)

sessionMBean.createSession(sessionName)

print(String(‘Session was created … ‘).concat(sessionName))

# Get the ProxyServiceConfigurationMBean specific to our session

mbean = findService(String(“ProxyServiceConfiguration.”).concat(sessionName),’com.bea.wli.sb.management.configuration.ProxyServiceConfigurationMBean’)

# Creates a reference to a folder.

# and ‘ProxyServices’ is a folder in the project

#folderRef = Refs.makeParentRef(‘project/’)

# and ‘ProxyServices’ is a folder in the project

projectName = Refs.makeParentRef(project + ‘/’)

proxyRef = Refs.makeProxyRef(projectName, service)

# do the action

def setService():

if action == ‘disable’:

print “Disabling ” Â + service

mbean.disableService(proxyRef)

else:

print “Enabling ” + service

mbean.enableService(proxyRef)

# or enable it

setService()

# Now commit (activate) the changes

sessionMBean.activateSession(sessionName, “disabled PS”)

print (‘ has been Â completed’)

disconnect()

exit()
