Installation of Oracle Enterprise Linux on VMWare

Patrick Sinke 7

Recently, Oracle announced and released it’s Enterprise linux. Time to check out what’s it all about!

While downloading the software from OTN, I was surprised to see there were no less than 8 discs, I downloaded all of them (a hefty 4.5 gigabytes) and found out after unzipping that the first 4 discs are installation discs and the other four contain only sources. The other four disks contain additional packages and software. So save yourself the bandwidth and cd-roms and start with the first four.

I do not have a spare machine for installing Linux so I installed VMWare Workstation and hooked up a 250 GB external harddisk. Let’s roll!

I use VMWare Workstation 5.0. I choose a pre-configured image which is named “Red Hat Enterprise Linux 4”. I was told OEL and Red Hay linux are very similar, so that should work fine. The imagesize is 15 gigabytes, and initially my virtual machine has 256 MB of memory assigned.

Booting the OS in VMWare:

booting VMWare

As you can see, the interface is modern and very user-friendly.

Welcome to Oracle Enterprise Linux

I save myself the trouble of pondering what partition should be which size, so I let the setup decide.
Disk partitioning setup


OEL does find my virtual disk and I choose to install the partitions in the free space available.automatic partitioning

It creates a 512MB swapdrive and the remaining space is one logical volume group. The partition type is ext3. It's fortunate to see that the size of the swapfile meets the minimum requirements for installation of Oracle Application server (which is also 512MB).disk setup

In the Package group selection step you can choose which tools and utilities you wish to install. Note the Server Configuration package which still mentions Red Hat instead of Oracle!


After all steps are followed, the actual installation begins.


That’s all folks!


Some post-installation tasks; confirm the license agreement, set date and time and create a system user.


And… Thunderbirds are Go! Now everything is working, it’s time to install your own software.


As you see, installing Linux goes without any pain. All the hardware works without tweaking, as well as the KDE graphical user interface. Really, I took me a lot more time to write this blog than to do the actual install. My guess of the total installation time: about half an hour.

Next action for me: installing Oracle 10g for Linux. But I’ll save that for the next blog!

7 thoughts on “Installation of Oracle Enterprise Linux on VMWare

  1. when trying to install compat-oracle-rhel4-1.0-5.i386.rpm on OEL 5 it is gving dependencies error and when the required dependencies are alreday installed

  2. Marco, I’m running Oracle Linux on a Dell Latitude D830, and I had the same problem. On VMWare Workstation 6.x, one of the hardware settings for the image is the Dispaly, which you can force to a max of 1024×768. As a result the os inside the image wont see anything resolution above that, and will configure appropriately upon install.


  3. Installation works like a charm. Unfortunately it ships with a very old jdk (1.4). Though the installation is free, updating software / packages is not. So far for evaluation purposes, Guess, I’ll to switch to another distro 🙁

  4. @Sander et all.

    Be careful installing the VMware tools only for screen optimizing purposes. At AMIS, we use wide screen laptops and VMware doesn’t know how to handle these. Luckily most Linux versions preserve a XF86Config file. So if you mess up your X configuration by installing VMware tools, try to find the saved backup XF86Config file and restore it. Until now, I haven’t found a suitable XF86Config file for our DELL latitude D820 laptops.

  5. I downloaded the Oracle Linux to install the Oracle EBS 11.5.10.
    Before you can install EBS 11.5.10 on this Linux version you must also install the following packages….

    – libaio-0.3.102-1.i386.rpm
    – libaio-devel-0.3.102-1.i386.rpm
    – openmotif21-2.1.30-11.FC2.1.i386.rpm

    And the following Oracle patch

    – ( compat-libcwait-2.1-1.i386.rpm + compat-oracle-rhel4-1.0-5.i386.rpm)

    Also, don’t forget to set the LD_ASSUME_KERNEL (=2.4.19)

  6. Don’t forget to install vmware tools into the Linux image.. and once you start installing other oracle products, like XE you will need to install the libaio package.
    For the current SOA Suite the installer will complain, because it does not recognize this Linux version, but you can easily avoid this with the -ignoresysprereqs option of the installer..
    As you can see, I’ve been there, done that.
