Android puts Oracle on the (Google) map.
0For a couple of months I have been discovering the Android platform. As an original Oracle developer I was wondering how an Android app can be connected to an Oracle database. For this purpose I developed an Android app that stores speed traps that users may hit while driving, into an Oracle database. The app also retrieves these speed traps from the database and draws them onto a Google map:
Fig. 1 After pressing the Android device’s menu button, two menu options ‘Retrieve’ and ‘Report’ (speed traps) appear.
Fig. 2 After pressing the ‘Retrieve’ option all speed traps already stored in the database appear as markers on the map.
Adding a custom method in an ADF BC Service Interface – update of a single attribute in a selected row
3The article “Quickly creating, deploying and testing a WebService interface for ADF Business Components” (http://technology.amis.nl/blog/9726/quickly-creating-reploying-and-testing-a-webservice-interface-for-adf-business-components) that I recently published describes a way of very rapidly creating the HRService Web Service – an ADF BC driven WebService on top of the EmployeesView ViewObject that exposes the EMPLOYEES table in the HR schema through the Employee EntityObject. However, that article’s true purpose is to show how to create the deployment profile and deploy and test this service, either on the integrated WLS or on a standalone WebLogic Server, in the easiest way possible. This article is an extension of the previous one: it demonstrates how to extend the Service Interface with a custom method (or an operation in terms of WebServices).
As it happens, I required an operation for updating just the salary of an Employee. I will show how I create a custom method in the Application Module’s implementation class, how I added this method to the Client Interface of the Application Module and subsequently to the Service Interface. After redeploying – using the same deployment More >
Quickly creating, deploying and testing a WebService interface for ADF Business Components
4As you probably already know, ADF Business Components can very easily be exposed through a WebService interface. An Application Module can be configured with a Service Interface, ordinary ViewObjects and custom methods can be exposed in that interface and deployment is relatively straightforward. In minutes, a WebService can be published that exposes operations based on regular ADF BC functionality. This may well give us the fastest way to provide data services on top of a relational database. Several excellent articles have been published on the ADF BC service interface, for example by Steve Muench and Andrejus Baranovskis.
The blog-article you are reading is created as the result of my research and investigations around an article I hope to publish in Oracle Magazine later in 2011. It is adamant for this article that readers can get the example to work with the smallest number of instructions possible – both to make their life easy and to save on words. The article describes a BPM process that interacts with the HR schema of an Oracle RDBMS as one of its activities. The focus in the article will be on BPM, not on exposing data services for the HR schema. The WebService should More >
Castle in the clouds – Building the Connexys SaaS application with Fusion Middleware
0SaaS applications serve users in many organizations from a single application instance running in a cloud. Common SaaS requirements include: customization including hiding and adding fields, managing boilerplate text & influencing the look & feel and a Service API for retrieving and manipulating data as well as allowing registration of listeners – applications outside the cloud that are notified by the SaaS application of events. Deep link navigation into the SaaS application allows visual integration with local applications.
Connexys provides a SaaS application (150+ customers) to support human resource and recruitment processes. The Connexys NextGen application is developed on Fusion Middleware using ADF. The application has an impressive number of specific SaaS enhancements (some inspired by Salesforce.com) that make it a compelling & competitive SaaS offering.
Below you will find the slides from the OBUG 2010 presentation that Arne van der Ing and I submitted and prepared for yesterday’s conference.
Come to our Forms2Future event (or “Oracle Classic and what next” event) on April 13th to here more about Connexys and other stories about moving to the future from current Oracle More >
SOA Suite 11g – Composite instance as WebService Result Cache using BPEL Correlation
This article describes an architectural pattern, implemented in the Oracle SOA Suite 11g, that is somewhat similar to the Oracle Database 11g Function Result Cache. It introduces a SOA Composite Application in the role of Result Cache. In its most simple form, the result cache is initialized – loaded with values -, used by other SOA applications that need the cached values, refreshed/reset when required and terminated. Through this ‘result cache’ – frequently used and not-so-frequently changed values that are published by (possibly remote, expensive or slow-reacting) web services or adapter services can be made available to local consumers in a simple, cheap and fast manner. We achieve this using the fast native SCA binding used for invoking in-container services exposed by fellow composite applications (that’s for speed) and the BPEL correlation mechanism (that’s for finding the result cache in the first place).
What the actual value of this pattern and implementation are is not yet entirely clear to me. Your feedback is appreciated. What I do know is that this article is also a good demonstration of using correlation and of applying some of the XML manipulation techniques More >
First Steps with RestLet 1.1RC2 in JDeveloper 11g – restful services 101
WebServices are hot. Some more so than others. SOAP based WebServices are frequently seen as not very lean and agile. Robust – perhaps. Widely supported – no doubt about it. Key element of almost any SOA infrastructure – sure. Easy, lightweight to deploy or to program a client against – no, not really. Inituitive? Bookmarkable? Addressable? – none of those. Restful web-services are the easy to use, lightweight, navigation oriented complement to the more heavy weight WS* SOAP based web services. REST is the natural extension of HTTP – leveraging a lot of its potential in a very direct way. REST services focus on Resources – that are searched & retrieved, created, updated and deleted. Resources can refer to each other – through hyperlinks that equal new REST service calls. The representation of Resources – the format of the response received or sent by a client has to be agreed upon; it usually is XHTML, XML or plain text.
Under JSR-311, a formal specification for REST is being developed, with project Jersey – nearing its completion – the reference implementation. An even more mature Java project for RESTful services is RestLet – a fairly easy to use library that allows for easy More >
