Create, Deploy and Consume an ADF Task Flow with ADF Business Components inside
I have discussed ADF Task Flows before in raving terms and with some simple example to prove my point. To be honest, I have never before really digged deep in any article into the use case of creating a bounded task flow that has ADF Business Components inside, deploying it to an ADF Library and reusing that Task Flow from that library in a completely different ADF application. That may not even have Business Components itself. Now is the time to remedy that omission. And also demonstrate how the consumed task flow – originating from somewhere in the Resource Catalog – can be integrated and synchronized with the consuming page.
It is not very difficult, but some steps must be observed to wire it together neatly.
Our objective in this article:
* Create a bounded task flow EmployeesList that uses ADF Business Components (in this particular case to display data from a database table called EMP, you may have hear it mention before) * Deploy the task flow to an ADF Library to make it reusable in other ADF applications * Create a new ADF Application in which the task flow EmployeesList is reused.
The steps we go through to accomplish this:
1. Create the Bounded Task Flow
2. Deploy More >
Introduction to ADF reusable task flows – consume a bounded task flow that gets synchronized with input parameter changes
Task Flows are the primary mechanism in ADF 11g for organizing the workload in manageable chunks that can be developed in a decoupled fashion in relative isolation, then merged together in web pages that implement the desired functionality. Task Flows are also one of the key mechanisms for reuse – along with but for other purposes than Page Templates, Page Fragments and Declarative Components. Task Flows are the key vehicle for creating encapsulated, stand alone services with a User Interface that can be consumed in multiple pages in various applications.
Task Flows come with their own managed beans, navigation rules, data binding, user interface – behind a fairly well defined interface which consists of input parameters and input/output events.
A few things that might be added to even improve a little on task flows: - a structured method for documentation and discovery, something like WSDL or JavaDoc to describe the meaning of the Task Flow and its input parameters - support for facets through which additional content can be injected into (views of) the task flow - support for page templates with facets predefined by the taskflow that can be associated with the views of the More >
ADF 11g: how events in one region cause other regions to refresh
One of the challenges in building Portal pages is to have events from one Portlet have the desired effect on other Portlets. For example when I select a location on a Map in one Portlet, other Portlets may need to be synchronized to show the weather, the best restaurants and the driving instructions for actually going there. The JSR-168 specification does not address this issue; the upcoming JSR-286 ("Portal 2.0") specs do. Working with ADF 11g, we have some fairly new mechanisms at our disposal, such as Task Flows and Regions, that allow us to construct pages (and applications) that are somewhat reminiscent of Portlets – or at least some of the interesting sides of Portlets in terms of creating relatively simple pieces of (stand-alone) functionality that can be wired together in a larger mashup – where ideally the mashup framework can provide event propagation between the stand alone pieces. In this article, I want to investigate how for example an event occuring in region A – based on a bounded taskflow – can be passed on to region B that is based on another bounded taskflow. (more…)
